Chatham Rev+ 2
Retrospec
Chatham Rev+ 2
✓ Free curbside shipping, continental U.S.
✓ Manufacturer warranty — claims handled by us
✓ Non-warranty returns: 20% restocking fee, original packaging
✓ Questions? (833) EBIKE-FL, 9–6 Eastern
Frameset:
Sizes: 18" Step Over;
Material: Alloy, 6061
Dropouts: 1x rear fender eyelets, rear rack mounts,
Replaceable Der Hanger: Yes
Fork: Steel
DriveTrain
Derailleur - Rear: Shimano Tourney 7 speed
Shifter: Shimano Tourney 7 speed
Crankset: 42T alloy
Chain: KMC Z7
BB: JIS square taper cartridge
Freewheel/Cog: Shimano 14-34T
Wheelset
Rims: Alloy 36H for disc brake
Hubs: Alloy bolt on 17mm nut
Spokes: 13G/2.3mm w/brass nipples
Tires: 26 x 3.0, with puncture protection
Components
Headset: Threadless, 1 1/8"
Brakes: Tektro mechanical with 180mm rotors and semi-metalic pads
Handlebars: Alloy cruiser
Grips: Comfort with alloy lock rings
Stem: Allpy quil
Saddle: Comfort Cruiser
Seatpost: Alloy; 25.4mm x 350mm
Seatpost Clamp: Alloy QR
Pedals: PP platform 9/16"
Extras
Kickstand: Rear mount, adjustable, aluminum alloy
Lights:Integrated/system operated front light w/ battery operated rear light
Fenders: Full coverage
Tools: 2/3/4/5/6mm hex wrench; 8/10/15/17mm open wrench; 13g spoke wrench
Weight -Max Rider: 350lbs / 158kgs not including bike weight
Class: Class 2: pedal-assist and/or throttle-assisted, 20 mph max.
E-Power System
Motor: 500W geared
Battery: 48V 500Wh
Modes: PAS/Thumb throttle Left side , cadence sensor
Display: B&W LCD center mount display with 6 levels of asist, anytime throttle and walk mode.
Controller: Retrospec 22Amp
Charge Time: Approximately 5-6hrs
Watt Hours: 500Wh
Range: 360Wh: 52+ Miles
Questions people actually ask
Does it arrive assembled?
It ships about 95% assembled in the manufacturer's box. Handlebars, front wheel, pedals and seat are the usual remaining steps, and the tools are in the box.
Who handles the warranty if something fails?
We do. The warranty is the manufacturer's, but the claim, the paperwork and the replacement part go through us. You have one phone number and one email, not a factory support queue.
How long does shipping take?
Free curbside delivery anywhere in the continental U.S. Most orders leave the manufacturer's warehouse within 2–4 business days; we send tracking as soon as it ships.
Can I return it?
If something's defective, the warranty claim goes through us at no cost to you — the manufacturer covers it. If you simply change your mind, we do accept the bike back, but a 20% restocking fee applies and it has to come back in its original factory packaging, unused and undamaged. Full written terms will be posted on our returns page.
